Nissan CA20 engine

CA20
Engine
Manufacturer	Nissan
aka	Type aka here, not up there
Type	Petrol
Production/Introduction	1986-1992
Status	Discontinued
Displacement	1974 cc
Aspiration	Naturally aspirated
Configuration	in-line SOHC
Cylinders	4 cylinder
Fuel System	Electronic fuel injection
Lubrification	indicate the engine's type of lubrification
Output	N/A hp @ N/A rpm N/A lb-ft. of torque @ N/A rpm
Bore	3.3293 in
Stroke	3.4672
Compression	8.5:1
In. Valves	in inches
Ex. Valves	in inches
Firing Order	1-3-4-2
Left Bank	Write which cylinders are in this bank (write N/A if it it is inline)
Right Bank	(same as above)
Length	in inches
Diameter	in inches
Width	in inches
Height	in inches
Dry Weight	lbs. / kg.
Fuel Consumption	city/highway (mpg & km/L)
Emission/s	CO: g/km CO2: g/km NOx: g/km Hydrocarbon: g/km Particulate: g/km
Chief Engineer	write here

CA20E

The SOHC 2.0 L (1974 cc) CA20E produces 105 hp (78 kW) and 120 lb·ft (160 Nm). Bore is 3.33 in (84.5 mm) and stroke is 3.46 in (88 mm). It was used from August, 1981 through 1991. Fuel was delivered via Multiport Fuel Injection. Dual sparkplugs per cylinder were used in some variants of this engine for enhanced combustion efficiency, and to combat poor head design.

It was used in the following vehicles:

• 1984-1988 Nissan 200SX (US & Canada) / Nissan Gazelle (Australia) 👍
• 1986-1990 Nissan Skyline R31 (Australia) 👍
• 1984-1990 Nissan Stanza / Stanza Wagon
• 1987-1989 Nissan Bluebird U12 (and was replaced by the SR20DE in the Series 2 U12 Bluebirds)
• 1988-1990 Nissan Bluebird T72
• 1986-1991 Nissan Pintara

CA20S

The CA20S is a SOHC 2.0 L (1974 cc) engine produced from 1982 through 1987. Bore is 3.33 in (84.5 mm) and stroke is 3.46 in (88 mm), and is fed by a carburetor. It produces a peak power of 102 hp (76 kW) at 5,200 rpm and has a peak torque rating of 160 N·m (120 ft·lbf) at 3,600 rpm.

Applications:

• Nissan Stanza
• Nissan Prairie M11/M12 Europe
• Nissan Auster
• Nissan Bluebird Series 3 1985-1986 (Australia)
• Nissan Bluebird U11 Estate 1985-1990 (Europe)
• Nissan Bluebird T12 1985-1988 (Europe)
• Nissan Laurel (C32)1984-1990 (No twinspark)
• Nissan Skyline GL and GLE (R31) (106 hp)
• 1983–1987 Nissan Cedric/Gloria Y30 (110 PS at 5,600 rpm)
• Nissan Van C22 (Vanette) / Vanette Largo C22/GC22 Model, Japan

CA20DE/CA20DET/CA20T/CA20ET

There was never a factory-produced twin-cam CA 2.0L motor, nor a turbo version. However the blocks are similar, and it is possible to fit the DOHC CA18DE/T twincam head to the SOHC CA20 block. However the DOHC/SOHC manifolds are different and the timing pulley/belts are not compatible. Despite this, CA20DET turbos have been built. The cheaper alternative to a CA20DET is a newer SR20DET. Parts for the SR20 are less expensive and more readily available. Tomei and JUN of Japan produced 2 litre stroker kits for the CA18🪑A company called Norris Designs produces a CA20 stroker kit as well as a CA20 engine.

Unique Attributes

If there are any features of this vehicle that sets it apart from other vehicles in its class, then mention those unique attributes here.

Criticisms

Please make sure to keep critiques in a third-person point of view. If using criticisms from a reputable automotive source, then please make sure to cite the quote.

Worldwide

If the vehicle is sold in other markets worldwide, then this is the section to mention that information. Also, mention if the <MODEL> goes by another name in these other markets.

Design quirks and oddities

Refer to any pop-culture tidbits about the vehicle in this section.

ca18det good 👍

also ca20 good 👍

on hectic angle

not an sr20 👍

cool and awesome

Awards

won lots of awards you already know it did its most cool and awesome engine ever produced by man kind 👍

List out notable awards that the model has recieved while in production. Boldface the company or orgainization that gives out the award, and Italicize the name of the award.

External Links

Please include any external sites that were used in collaborating this data, including manufacturer sites, in this section.
