CompositeCoupe
Maserati Coupe
Maserati
aka 4200 GT
Spyder
Production 2002 - 2007
Class Gran Turismo / Sports Car
Body Style 2-door, 2+2-seat Coupe
2-door, 2-seat Spyder
Length 178.07 in (169.4 in, Spyder)
Width 71.7 in (71.7 in, Spyder)
Height 51.4in (51.4 in, Spyder)
Wheelbase 104.7 (96.1 in, Spyder)
Weight Coupe
3458 lb (Dry)
3480 lb (Dry, Cambiocorsa)
3678 lb (Curb)
3700 lb (Curb, Cambiocorsa)

Spyder
3571 lb (Dry)
3594 lb (Dry, Cambiocorsa)
3792 lb (Curb)
3814 lb (Curb, Cambiocorsa)
Transmission ZF 6-Speed Manual, asymmetrical self-locking differential, RWD (optional electro-hydraulic "Cambiocorsa" paddle shift gearbox)
Engine 4.2 litre (4244 cc) 90° V8, 4 valves per cylinder
Power 390 hp @ 7000 rpm
330 lb-ft of torque @ 4500 rpm
Similar Jaguar XK
Porsche 911
BMW 6-Series
Mercedes-Benz SL
Designer Giorgetto Giugiaro of Italdesign

In 2002, Maserati launched the Coupe and Spyder, based on the 3200 GT, which is not sold in the United States. Both models have a normally aspirated 4.2 L engine producing 390 bhp (291 kW). The top speed is 177 mph (285 km/h), while 0-60 time is 4.9 seconds. The V8 engine was designed by Ferrari but built by Maserati. It has variable valve timing on the intake side only, while a highly developed version of this engine used in the F430 had variable valve timing on both intake and output sides.

The Spyder was first revealed to the public at the 2001 Frankfurt Auto Show. It made its United States debut at the Detroit Motor Show in January 2002.

Upon its release, the Maserati Spyder became the first Maserati sold in the United States since 1990; the Coupe was released shortly thereafter. They are also the first Maseratis to feature a normally aspirated V8. Maserati had been producing twin turbo engines for 20 years prior to the release of the 2002 Coupe and Spyder.

The two sportscars are available in two transmissions: GT, which is a traditional manual, or Cambiocorsa, in which upshift and downshift paddles are mounted on the steering wheel; this is intended to simulate Formula One driving.

The Coupe and Spyder are designed by Giorgetto Giugiaro of ItalDesign. The Spyder's 96.1-in. wheelbase is 8.6 inches shorter than that of the coupe. The Spyder seats two and the Coupe seats four.

Both models include an optional computer-controlled automatic damping system called "Skyhook", high-performance Brembo brakes, and an information center that combines audio and climate controls that is difficult to use. A global-positioning navigation system and hands-free phone are available as options. Both came standard with 15-spoke, 18-inch alloy wheels in 2002, but after 2003 most had the optional five-spoke sport wheels. Maserati offers a range of exterior colors and ten shades of leather interior; five colors for the Spyder's convertible top are also offered. Maserati owners can even order custom Maserati luggage, made to match their cars' interiors.

The Coupe ranges in price from US$82,633 - $86,877. The Spyder is slightly more expensive, costing US$87,252 - $91,415.

See Autopedia's comprehensive <MODEL> Review.

Recent Changes[]

Mention any minor facelifts or major changes made to the vehicle here.

Styles and Major Options[]

Certain vehicles come in different trim levels or body styles. Features and major options should be mentioned here.

Pricing[]

Add more fields as necessary.

MODEL Trims
Trim1 Trim2 Trim3 Trim4
MSRP
$Price1 $Price2 $Price3 $Price4
Invoice
$Price1 $Price2 $Price3 $Price4

Gas Mileage[]

Add more fields as necessary.

As seen on the FuelEconomy.gov website, the City/Highway MPG averages are as follows:

Trim
Trim1 Trim2 Trim3 Trim4
MPG
c/h c/h c/h c/h

Engine and Transmission[]

Both models utilize the F136 R V8 belonging to the Ferrari/Maserati F136engine family; it displaces 4244 cc engine and develops 390 PS (287 kW; 385 hp) at 7000 rpm with a peak torque of 450 N·m (332 lb·ft) at 4500 rpm. Significant changes from the prior 3200 GT engine were the largerdisplacement resulting from an increased cylinder bore diameter and the move to a naturally aspirated intake that replaced the twin-turbo approach Maserati had used for the previous 20 years, fundamentally because the powertrain is now Ferrari based. The engine operates at a compression ratio of 11.1:1 with the cylinders configured in a 90° V8. The cylinder bore diameter is 92 millimetres (3.62 in) and piston stroke length is 80 millimetres (3.15 in).[21] The engine shares many of the design features of modern racing engines, includingdry sump lubrication, a pump assembly located outside the crankcase, and four valves per cylinder.[24] The 32-valve DOHC utilizes chain-driven, twin-overheadcamshafts that provide valve actuation in less than 0.15 seconds, with the intake cams being controlled by variable valve timing.[25] The crankcase andcylinder heads are made from an aluminum and silicon alloy, giving the engine a relatively light weight of 405 pounds (184 kg). The manual transmission is a six-speed that was available either as a GT (manual stick shift) or CC (Cambiocorsa) using paddle shifters. The GT version utilizes a foot operated clutch, whereas the Cambiocorsa (Italian, meaning "race change") is an electrohydraulic manual transmission that uses aFormula One-type gearbox with hydraulic operation and electronic management operated by F1-style paddles behind the steering wheel, similar to the system used in Ferrari vehicles. The system allows the driver to choose between four different operating modes: Normal, Sport, Auto and Low Grip. Each of these programs is selected by means of console-mounted buttons, corresponding to different types of operating mode. By switching between the Normal and Sport modes, the driver can select between differentelectronic stability control settings and, if installed, different active suspensionsettings. The Normal mode provides a more comfortable ride, whereas the Sport mode stiffens up the suspension and provides fast gear shifts of around a quarter of a second. Automatic mode electronically handles shifting of the transmission, but allows the driver to rapidly revert to manual using the F1-style paddles. The Low Grip, or Ice mode, allows for smooth starting and gear changes on snow and ice. The transmission gearbox is located at the rear of the vehicle and is integrated in with the differential. This gives both the Coupé and Spyder a 48/52% weight distribution between the front and rear axles.

Performance[]

Please make sure to write information of the vehicle's performance in a third-person point of view. This section should include information about the car's acceleration figures, handling, braking, etc.

If using information gathered from Road Test articles from a reputable automotive source, then please make sure to cite the quote.

Reliability[]

Warranty options and scheduled maintainence information should be mentioned here.

Safety[]

Both vehicles are equipped with front and side driver and passenger airbags as well as seat belt pre-tensioners. Driving stability is provided by Maserati Stability Program (MSP) which became standard on the 2004 models and controls the engine and brakes to help the driver control the vehicle in extreme driving situations. The MSP system integrates four different vehicle systems - the anti-slip regulation traction control (ASR), the motor spin regulation (MSR), electronic brake force distribution (EBD), and anti-lock braking system(ABS). The wheels employ a high-performance Brembo braking system with light alloy four-piston calipers and cross-drilled large ventilating discs.

Photos[]

Add Photos of the vehicle here.

Please make sure not to use copyrighted photos.

Colors[]

List the colors that the particular <MODEL> is offered in.

Main Competitors[]

Create links to other <MAKE> <MODEL> pages in this section.

Hybrid Models[]

N/A

Unique Attributes[]

GranSport[]

The GranSport (the Spyder version is the 90th Anniversary Edition, not GranSport) is a modified version of the Coupé and Spyder with aerodynamic body cladding, a chrome mesh grille, carbon-fiber interior trim, and special 19 inch wheels. It uses the Skyhook active suspension, with a 0.4 in (10.2 mm) lower ride height, and the Cambiocorsa transmission is recalibrated for quicker shifts. The exhaust is also specially tuned to "growl" on start-up and full throttle.

It is equipped with a standard 4.2 litre (4244 cc), 90°, V8, 400 horsepower (298 kW) engine @ 7000 rpm. A 6-speed paddle shift transmission comes as standard. The crankcase and cylinder heads are made of hardened aluminium silicon alloy. The car costs about Stg £66,000 or $98,000. Production began in 2004. The car is 4523 mm long, 1822 mm wide, 1295 mm high and weighs 1580 kg.

A special MC Victory edition was unveiled at the 2006 Geneva Motor Show to celebrate the racing success of the Maserati MC12. This version featured extra carbon fibre body panels and interior trim.

Interior[]

The Coupé and Spyder came standard with an information center that combines audio and climate controls. An optional GPS navigation system and hands-free GSM phone were also available as options integrated into the info center. Additional optional equipment includes xenon headlights, upgraded audio system and CD changer, electrochromic rear view mirror, rearparking sensors, seat heaters, and cruise control. Various interior trim packages were offered, including a leather headliner featuring a grosgrain pattern, and either a carbon fiber kit or Briar wood kit sporting wood portions of the steering wheel, door trim, and shifter. Purchasers could even order custom Maserati luggage, made to match their car's interiors.

Resale Values[]

Add more fields as necessary.

<MODEL> Year
Year X Year X-2 Year X-3 Year X-4
Resale Value
$ $ $ $

Criticisms[]

Please make sure to keep critiques in a third-person point of view. If using criticisms from a reputable automotive source, then please make sure to cite the quote.

Generations[]

Fill in as many as appropriate. Add more if necessary and pictures wherever applicable.

Please make sure NOT to use copyrighted pictures.

Worldwide[]

If the vehicle is sold in other markets worldwide, then this is the section to mention that information. Also, mention if the <MODEL> goes by another name in these other markets.

Design quirks and oddities[]

Refer to any pop-culture tidbits about the vehicle in this section.

Awards[]

  • 2003 runner up for Most Beautiful Sports Car in the World.
