Jaguar XJR-15

Jaguar XJR-15
Jaguar
aka	R9R
Production	1990 (50 units)
Class	Sports car
Body Style	2-Door Coupe
Length	188.9 in (4800 mm)
Width	74.8 in (1900 mm)
Height	43.3 in (1100 mm)
Wheelbase	107.0 in (2718mm)
Weight	2,315 lb (1050kg)
Transmission	6 speed manual, rear wheel drive
Engine	6.0-litre V12
Power	450bhp (335 KW) @ 6250rpm 420 lb ft (569 Nm) @ 4500rpm
Similar	Jaguar XJ220
Designer	Peter Stevens

The Jaguar XJR-15 is a rare supercar produced by Jaguar. Only 50 were made, each selling for US$960,165. Based mechanically on the Le Mans-winning Jaguar XJR-9, the car had an aerodynamic body designed by Peter Stevens, who later went on to design the McLaren F1.

The car's production was announced in a press release on November 15, 1990. It was then built by Jaguar Sport in Coventry, England from 1990 to 1992. While all are now privately owned, some were built for professional racing.

The mid-engine, rear-wheel drive supercar is powered by a 450 bhp, naturally aspirated V12 engine of 5,993cc, and has a 6-speed manual transmission. The XJR-15’s chassis and bodywork are composed of carbon fiber and Kevlar, and its engine features an advanced electronically managed fuel injection system. The XJR-15 has a 0-60 mph time of 3.1 seconds and a top speed of 185 mph.

Because of its V12 engine, power-hungry buyers saw the XJR-15 as an attractive alternative to the Jaguar XJ220, which was powered by a twin turbo V6. The XJ220 was also a limited production vehicle, of which 271 were built.

The XJR-15 stemmed from a concept car by Jaguar Sport and Tom Walkinshaw Racing (TWR) called Project R9R. The R9R was developed by Jaguar Sport for the purpose of testing the endurance of carbon and plastic bodywork at high speeds. It was based mechanically on the V12-powered XJR-9, which won the 1988 Le Mans. After thousands of miles of testing and thorough analysis, the R9R went into production as the Jaguar XJR-15 in 1990. According to a press release by Jaguar, it was built specifically with the 1991 Jaguar Sport Intercontinental Challenge in mind.

Sixteen of the cars were raced at the 1991 Jaguar Sport Intercontinental Challenge in Monaco. The event was a three-race competition held throughout the year as a support race to the Formula One Grand Prix. The winner of the final race at Spa-Francorchamps, Armin Hahne, was awarded a cash prize of US$1 million.

While Jaguar never exported the XJR-15 out of Europe, at least three are known to have made their way to the United States. One was sold at the Pebble Beach Concours d’Elegance in 2001 for US$176,000. Another was sold at Pebble Beach in 2003 for US$154,000 (which was, incidentally, alongside a Jaguar XJ220 which sold for US$157,500).

The most recent was sold at the Bonhams & Butterfields Auction in Carmel, CA in August 2004. It is reported to have been sold to a private collector for around US$175,000. The auctioned car in question was originally ordered in 1991 by British pop music producer Matt Aitken, who participated in races supporting that year's Monaco Grand Prix and Belgian Grand Prix.

History

Tom Walkinshaw conceived the concept in 1988 after seeing the XJ220 concept at the British Motor Show. Following Jaguar's success at Le Mans, he enlisted Peter Stevens to develop a road-going version of the XJR-9,[3] originally designated the R-9R. A number of wealthy racing enthusiasts were keen to own such a car and pressed Walkinshaw into manufacturing a 'road going racer'. This car was originally intended to be a better alternative to the XJ220. Original owners included Derek Warwick, Bob Wollek, Vern Schuppan, Matt Aitken, Andy Evans and the Sultan of Brunei.

In order to adapt the XJR-9 for road use, Stevens made a number of modifications to increase space and improve access. "Taking the race car as a base, we widened the cockpit by 75 mm (3.0 in) and raised the roof by 40 mm (1.6 in) to allow more headroom", he said when interviewed in 1991.[4] "The scale model was ready by Easter 1989, from there we went to clay... which was finished by October (1989). The first prototype was held up by Le Mans preparations but it was ready for Tom (Walkinshaw) to drive when he came back from France in July 1990".

TWR explicitly developed the XJR-15 as a road-going racing car, in the mould of the Jaguar C and D types, the Ford GT40 and the Ferrari 250 GTO. As such, the car complied with British construction and use regulations and could be registered by the owner for road-use in the UK, although with such a limited production run, the car was never type-approved.

The car's production was announced in a press release on 15 November 1990 with an official launch at Silverstone early in 1991. The XJR-15 was built by JaguarSport in Bloxham, Oxfordshire, (a subsidiary of TWR; it was a joint venture between Jaguar Cars and TWR to produce high performance sports cars) England from 1990 to 1992 and had no official involvement from Jaguar itself.

Design and reception

The XJR-15 is powered by a 5,993 cc (6.0 L) 450 hp (336 kW), naturally aspirated 24-valve Jaguar V12 engine. The engine features an advanced electronically managed fuel injection system with a very advanced (for its time) 'fly by wire' throttle. The standard transmission is a TWR unsynchronised six-speed manual transmission while a five-speed, synchromesh transmission was also available as an optional extra.

The XJR-15's chassis and bodywork are composed of carbon fibre and Kevlar (it was the first road-going car built entirely of carbon and Kevlar composites,[5] before the McLaren F1 used similar construction techniques in 1992). The overall proportions differed from the XJR-9, with the XJR-15 being 480 cm long, 190 cm wide and 110 cm tall. The final weight amounted to be 1,050 kg (2,315 lb).

A fully independent suspension was used, with non-adjustable Bilstein shock absorbers all round. Front suspension consists of wide-based wishbones and working push-rods to spring damper units mounted horizontally across the centre of the car. The car retains the rear suspension unit from the XJR-9 with vertical coil-springs mounted in units with uprights within the rear wheels, allowing for the maximum possible venturi tunnels. The engine forms a stressed member for the rear-frame. The bottom of the car is completely flat, in line with Group C practice.

The ride height was somewhat higher than required to take full advantage of under-body aerodynamics due to the road going nature of the car. Additionally, the suspension was softer than would be found on the XJR-9 racer and - in a last-minute deal - Tom Walkinshaw switched tyre suppliers from Goodyear to Bridgestone just before the race series started. When interviewed by Autosport[6] in 2011, Ian Flux recalled: "The worst thing was that Tom had done a deal with Bridgestone. At first, it was going to be on road tyres, but then they changed to slicks and wets. The fronts weren't a problem, but they didn't have moulds for the rears, so used F40 moulds instead. They went off very quickly and it was hard to judge how hard to push."

As Tiff Needell, who road-tested a development car at Silverstone early in 1991, put it: "the result is oversteer". However, once accustomed to the characteristics, he went on: "Through the very tight chicane, the XJR-15 showed excellent change of direction and I was able to pick up power early for the long right hander leading up to Beckett's. This gradually became a long right-hand power slide as my confidence increased."

Ron Grable, the racing driver, writing in Motor Trend in May 1992:[8] "As the engine sprang into a muted rumbling idle, it was impossible to keep from grinning. Easing the unsynchronised six-speed into gear, I accelerated onto the straight. Many race cars are diabolical to get moving...not so the Jag, the smooth V-12 pulled cleanly away, nearly as docile as a street-car. On the track, the XJR-15 is a truly wonderful ride, the perfect compromise between racing and street. You can say the savage edge of a pure race car has been softened slightly, or conversely, that it's the best handling street car you can imagine. Being 100% composite, it's so light that every aspect of performance is enhanced. Relatively low spring and roll rates are enough to keep it stable in pitch and roll, as well as deliver a high level of ride compliance. The brakes are phenomenal and the acceleration fierce. And always, there's that V-12, a medley of mechanical noises superimposed over the raucous rise and fall of the exhaust."

The XJR-15 offers little in the way of practicality. Entry to the car, over a wide sill, requires the driver to step onto the driving seat. The gear-lever is mounted on the right-hand side of the driver (all cars are right-hand-drive), while the driver and passenger seat are extremely close together - almost central in the car. Due to minimal sound insulation, an in-car head-set system is fitted. There is no storage space in the car due to its race car like nature. However, considering the purpose for which it was intended, the interior was highly praised in contemporary automotive press publications. Ron Grable wrote: "Aesthetically, the XJR-15's interior is breathtaking. Expanses of shiny black carbon fibre woven with yellow Kevlar are everywhere, all fitting together with meticulous precision. Instrumentation is detailed and legibly analogue. The shift lever is less than 3 inches (76 mm) from the small steering wheel, and the motion between gears is almost imperceptible. The reclined seating position provides excellent forward visibility - over the top of the instrument panel you see only racetrack."

Media appearances

Cars 2

Holley Shiftwell is a supporting character in Cars 2. She is voiced by Emily Mortimer. The likelihood of her being A XJR-15 are very unlikely, as she resembles many other cars.

Forza Horizon 5

The XJR-15 was featured in the 5th entry to the iconic Forza Horizon series as a 'barn find' obtained early on in the story.
