Isuzu F-Series

This vehicle is about an Isuzu vehicle. For the pickup truck produced in the Ford Motor Company, see Ford F-Series.

Isuzu F-Series
Isuzu Truck
aka	Chevrolet T-Series GMC T-Series
Production	1990 - Present
Class	5, 6, 7 and 8 Heavy Duty
Body Style	2-Door Cabover Truck
Length
Width
Height
Wheelbase	109.0 - 176.0 in.
Weight
Transmission	Allison 2200 5-Speed Ausomatic Eaton-Fuller 6-Speed Manual Allison 3000RDS 6-Speed Automatic Eaton-Fuller 9-Speed Manual Eaton-Fuller RT8908LL 10-Speed Manual
Engine	7.8 liter Isuzu 6HK1-TC Turbocharged and Intercooled inline-6
Power	Various Levels of Tune. Please see chart below.
Similar	Hino Ranger Mitsubishi Fuso Fighter Nissan Diesel Condor
Designer

The Isuzu F-Series medium/heavy duty cab-over trucks are positioned higher in capacity than the N-Series models. The F-Series shares components with the N-Series, but offers a higher payload and Gross Vehicle ratings as well as the more powerful Isuzu 6H engine family. The Isuzu F-Series is marketed towards heavy delivery applications using stake and van bodies. The base model F-Series is the FTR, with a GCWR of 25,950 lbs and either a 170- or 212-in. wheelbase. The mid-payload FVR is available with weight ratings from 25,950- to 35,000-lbs. and a 212-in. wheelbase (140-in. on 35,000 GCWR models). The FXR heavy duty model features a 33,000 lb. GCWR and 250 hp engine on single rear axle models, and a 56,000 lb. GCWR and 275 hp engine on tandem rear axle models.

File:Fxr tandem.jpg

FXR Tandem chassis

File:Fvr dump.jpg

FVR with a dump flatbed body

Complete specifications can be found at the Isuzu F-Series Specifications website.

Isuzu FTR Specifications
GVWR/GCWR		25,950 lbs.	25,950 lbs.
Wheelbase		170 in.	212 in.
Engine	Displacement Horsepower (All @ 2400 RPM) Torque (All @ 1500 RPM)	7.8L (475 CID) 200 441	7.8L (475 CID) 200 441
Transmission	Automatic Manual	Allison 2200 5-Speed Eaton-Fuller 6-Speed	Allison 2200 5-Speed Eaton-Fuller 6-Speed
Front Axle (I-beam)	Rating	10,000 lbs.	10,000 lbs.
Front Suspension (Tapered leaf)	Rating	10,000 lbs.	10,000 lbs.
Rear Axle	Rating Ratio A/T Ratio M/T	19,000 lbs. 4.11:1 3.08:1	19,000 lbs. 4.33:1 3.08:1
Rear Suspension	Rating	19,000 lbs. Multi-leaf	19,000 lbs. Multi-leaf



Isuzu FVR Specifications
GVWR/GCWR		25,950 lbs.	25,950 lbs.	25,950 lbs.	25,950 lbs.	33,000 lbs.	35,000 lbs.
Wheelbase		212 in.	212 in.	212 in.	212 in.	212 in.	140 in.
Engine	Displacement Horsepower (All @ 2200 RPM) Torque (All @ 1450 RPM)	7.8L (475 CID) 200 520	7.8L (475 CID) 200 or 230 520 or 660	7.8L (475 CID) 200 520	7.8L (475 CID) 230 660	7.8L (475 CID) 250 800	7.8L (475 CID) 250 800
Transmission	Automatic Manual	Allison 2200 5-Speed Eaton-Fuller 6-Speed	Allison 2200 5-Speed Eaton-Fuller 6-Speed	Allison 2200 5-Speed Eaton-Fuller 6-Speed	- Eaton-Fuller 6-Speed	Allison 3000RDS 6-Speed Eaton-Fuller 6-Speed	Allison 3000RDS 6-Speed Eaton-Fuller 9-Speed
Front Axle (I-beam)	Rating	10,000 lbs.	10,000 lbs.	12,000 lbs.	12,000 lbs.	12,000 lbs.	12,000 lbs.
Front Suspension (Tapered leaf)	Rating	10,000 lbs.	10,000 lbs.	12,000 lbs.	12,000 lbs.	12,000 lbs.	12,000 lbs.
Rear Axle	Rating Ratio A/T Ratio M/T	19,000 lbs. 5.29:1 3.90:1	19,000 lbs. 5.29:1 3.90:1	19,000 lbs. 5.29:1 3.90:1	19,000 lbs.  - 3.90:1	21,000 lbs. 5.57:1 3.90:1	23,000 lbs. 5.57:1 3.90:1
Rear Suspension	Rating	19,000 lbs. Air Ride 21,000 lbs. Multi-leaf	21,000 lbs. Multi-leaf	21,000 lbs. Multi-leaf	21,000 lbs. Multi-leaf	23,500 lbs. Multi-leaf	23,500 lbs. Multi-leaf



Isuzu FXR Specifications
GVWR/GCWR		33,000 lbs.	56,000 lbs. (Tandem)	56,000 lbs. (Tandem)
Wheelbase		212 in.	236 in.	236 in.
Engine	Displacement Horsepower (All @ 2200 RPM) Torque (All @ 1450 RPM)	7.8L (475 CID) 250 800	7.8L (475 CID) 275 800	7.8L (475 CID) 275 800
Transmission	Automatic Manual	Allison 3000RDS 6-Speed  -	Allison 3000RDS 6-Speed  -	- Eaton-Fuller RT8908LL 10-Speed
Front Axle (I-beam)	Rating	12,000 lbs.	16,000 lbs.	16,000 lbs.
Front Suspension (Tapered leaf)	Rating	12,000 lbs. Tapered leaf	18,000 lbs. Multi-leaf	18,000 lbs. Multi-leaf
Rear Axle	Rating Ratio	21,000 lbs. 5.57:1	40,000 lbs. 5.57:1	40,000 lbs. 3.90:1
Rear Suspension	Rating	23,000 lbs. Multi-leaf	40,000 lbs. Hendrickson Walking Beam	40,000 lbs. Hendrickson Walking Beam
