The Chrysler Airflow was an automobile produced by the Chrysler Corporation from 1934 to 1937. The Airflow was the first full-size American production car to use streamlining as a basis for building a sleeker automobile, one less susceptible to air resistance. Chrysler made the first effort at a fundamental change in automotive design with the Chrysler Airflow, which ultimately represented one of the most serious miscalculations in automotive history.
Genesis of the Airflow project[edit | edit source]
The basis for the Chrysler Airflow was rooted in Chrysler Engineering's Carl Breer's curiosity about how forms affected their movement through the environment. According to Chrysler, Breer's quest was started while watching geese travel through the air in a "V" flight pattern. Another source lists Breer as watching military planes on their practice maneuvers, while still other sources attach the genesis of the project to Breer's interest in lighter than air airships and how their shapes helped them move through the atmosphere.
Breer, along with fellow Chrysler engineers Fred Zeder and Owen Skelton, began a series of wind tunnel tests, with the cooperation of Orville Wright, to study which forms were the most efficient shape created by nature that could suit an automobile. Chrysler built a wind tunnel at the Highland Park site, and tested at least 50 scale models by April 1930. Their engineers found that then-current two-box automobile design was so aerodynamically inefficient, that it was actually more efficient turned around backwards. Applying what they had learned about shape, the engineers also began looking into ways that a car could be built, which also used monocoque (unibody) construction to both strengthen the construction of the car while reducing its overall weight, and thus increasing the power output by the engine as the lighter, more streamlined body allowed air to flow around it instead of being caught through upright forms, such as radiator grilles, headlights and windshields.
Traditional automobiles of the day were the typical two-box design, with about 65% of the weight over the rear wheels. When loaded with passengers, the weight distribution tended to become further imbalanced, rising to 75% or more over the rear wheels, resulting in unsafe handling characteristics on slippery roads. Spring rates in the rear of traditional vehicles were, therefore, necessarily higher, and passengers were subjected to a harsher ride.
An innovative suspension system on the new Chrysler Airflow stemmed from the need for superior handling dynamics. The engine was moved forward over the front wheels compared with traditional automobiles of the time, and passengers were all moved forward so that they were seated within the wheelbase, rather than on top of the rear axle. The weight distribution had approximately 54% of the weight over the front wheels, which evened to near 50-50 with passengers, and resulted in more equal spring rates, better handling, and far superior ride quality.
The Airflow debuts[edit | edit source]
Prior to the Airflow's debut, Chrysler did a publicity stunt in which they reversed the axles and steering gear, which allowed the car to be driven "backwards" throughout Detroit. The stunt caused a near panic, but the marketing department felt that this would send a hint that Chrysler was planning something big. The car that emerged was like no other American production car to date.
The Airflow, which was heavily influenced by streamlining design movement, was sleek and low compared to other cars on American roads. The car's grille work cascaded forward and downward forming an arc where other makes sported bolt-upright radiators. Headlights were semi-flush to areas immediate to the grille. The front fenders enclosed the running surface of the tire tread. In the rear, Airflows encased the rear wheels through the use of fender skirts.
Instead of a flat panel of glass, the windshield was comprised of two sheets of glass that formed a raked "vee" both side to side, and top to bottom. Passengers were carried in a full steel body (at a time when automakers like General Motors, Ford and even Chrysler itself continued to use wood structural framing members in their car bodies) that rested between the wheels instead of upon them. The front seat was wider than in other cars and the rear seat was deeper. Overall, the car possessed a better weight to power ratio, and its structural integrity was stronger than other like models of the day.
However, the car was introduced months before it was put in production, and production peaked at only 6,212 units in May 1934 – very late in the year and barely enough to give every dealer a single Chrysler Airflow. The factory had not accounted for significant manufacturing challenges and expense due to the unusual new Airflow design, which required an unprecedented number and variety of welding techniques. The early Airflows arriving at dealerships suffered from significant problems, mostly the result of faulty manufacturing. According to Fred Breer, son of Chrysler Engineer Carl Breer, the first 2,000 to 3,000 Airflows to leave the factory had major defects including engines breaking loose from their mountings at 80 mph.
1934[edit | edit source]
For 1934, both Chrysler and its junior running mate, DeSoto, were scheduled to offer the Airflow. DeSoto was assigned to offer nothing but Airflows; Chrysler, however hedged its bets and continued to offer a six-cylinder variant of its more mainstream 1933 model cars. The Airflow used a flathead I8 engine and was produced in both 2-door coupe and 4-door sedan variants.
Within six months following the introduction of the Airflow, the vehicle was already a sales disaster. Adding insult to injury, General Motors mounted an advertising campaign aimed at further discrediting the Airflows. Most automotive historians, though, agree that the Airflow was shunned in large part because buyers did not like its looks. The hood, waterfall grille, headlamps and fenders were all merged into one anonymous lump. While thoroughly modern, the public was slow to embrace the Airflow. At the depth of the Great Depression, the car seemed to be too advanced, too different for many consumers. While Airflows sold in respectable numbers in its first year, Chrysler's traditional sedans and coupes far outsold the Airflow by a ratio of 2.5 to one, with first year Airflow sales at 10,839 units.
DeSoto faired far worse than Chrysler for 1934. Without any "standard" car to sell, DeSoto's sales numbers plunged. And while the Airflow design looked somewhat sleek on the Chrysler's longer wheelbase, the DeSoto appeared to be short and stubby.
Rumors also persisted that the "new-fangled" body was unsafe, which was mostly true. In one widely distributed advertising film shown in movie theatres, an empty Airflow was pushed off a Pennsylvania cliff, falling over 110 feet; once righted, the car was driven off, battered, but recognizable. Although seemingly safe, modern cars are made to crush in certain areas. These crush zones allow more time for the car to decelerate which results in less of an impact for the passengers.
1935[edit | edit source]
Stung by the lack of consumer interest in the car, Chrysler responded by making modifications to the body that brought the front of the car more in line with public taste. Foremost of 1935 changes was the placement of a slightly peaked grille that replaced the waterfall unit of 1934.
Chrysler also introduced an all-steel standard car, which it and DeSoto sold as the Chrysler Airstream and DeSoto Airstream. The Airstream was popular and outsold the Airflow models because while the Airflow was streamlined, the Airstream only looked streamlined.
Chrysler Airflow production dipped below 8,000 units for 1935, with roughly four Airstreams produced for every Airflow.
1936[edit | edit source]
For 1936, the Airflow surrendered its smooth backside when a trunk was tacked onto the body of the car. The grille also became more pronounced. Only one Airflow body style, the four-door Imperial sedan (C-10) broke the 1,000 unit mark with 4,259 units built. Otherwise, total Airflow production sunk to 6,275 units compared to the concurrent Airstream models, which sold more than 52,000 units for 1935. 1935 would be the last year that Chrysler's premium Imperial model range would carry the Airflow.
1937[edit | edit source]
In its final year, the Airflow was reduced to one model, offered as a two-door and four-door sedan. A total of 4,600 units were produced before the program was canceled. It was in this year that an Airflow limousine became the official car of Philippines president Manuel L. Quezon. The historic vehicle was restored in 1978 and is on display in Quezon City, Philippines.
After effects[edit | edit source]
While the Airflow may have signaled Chrysler's attempt to set itself apart from other manufacturers, the failure of the car in the marketplace caused the company to take a more conservative path with its future models. Until the debut of Virgil Exner's "Forward Look" cars of 1955, Chrysler's corporate styling was conservative and mainstream.
Today, most cars are designed with the aid of wind tunnels, and cars like the aero Thunderbird and Taurus enjoyed very high sales. Although the Airflow hasn't attracted the number of models and Hot Wheels as say, the Cord or Duesenberg, many die cast models are still available, and one die cast pre-war toy sold on eBay in 2006 for $5,000, which is about what these cars cost new. The Airflow consistently shows up on anyone's list of top 10 most important or classic cars of its era.
